| Engine Information |
| EPA certificated |
| Engine type |
4-stroke, single cylinder, water cooled |
| Displacement |
300 cc |
| Max HP: |
17.4hp/6500rpm |
| Max torque: |
16 lb ft/5000rpm |
| Bore x stroke: |
2.85 x 2.63 inches |
| Max speed: |
50mph |
| Climbing ability: |
18 degrees |
| Ignition: |
C.D.I |
| Starter system： |
Electric Start |
| Battery: |
12V 10Ah |
| Carburetor brand: |
JF (RX) |
|
Engine oil: |
SAE 15W-40 |
| Gear oil: |
|
|
|
| General Information |
| Clutch: |
Automatic CVT |
| Driveline / Driving wheel: |
Chain / Dual wheel drive |
| Suspension, F / R: |
Double Oil Damped Shock |
| Brakes, F / R: |
No / Hydraulic brake, Disc |
| Tires, F / R: |
145/70-6 / 16x6-8 |
| Fuel capacity: |
1 gal |
| Weight, G.W. / N.W.: |
386 / 330 lbs |
| Max load: |
400 lbs |
|
| Dimension Information |
| Wheelbase: |
48.4 inches |
| OA L x W x H: |
67x43.3x51.2 inches |
| Height to seat: |
10.2 inche |
| Min ground clearance: |
2.8 inches |
| Pedal to seat back distance: |
31.5 to 34.5 inches |
| Qty/Container: |
54pcs/40'HQ |
|
Colors
|
RED
BLUE
BLACK
YELLOW
ORANGE
PINK
SILVER |
|
|
