| Engine Information |
| EPA certificated |
| Engine type |
4-stroke, single cylinder, water cooled |
| Displacement |
250cc |
| Max HP: |
14.08hp/6000rpm |
| Max torque: |
13 lb ft/6000rpm |
| Bore x stroke: |
2.83x2.36 inches |
| Max speed: |
50mph |
| Climbing ability: |
20 degrees |
| Ignition: |
C.D.I |
| Starter system： |
Electric Start |
| Battery: |
12V 10Ah |
| Carburetor brand: |
VEKS4 & CV30 |
|
Engine oil: |
SAE 15W-40/SF |
| Gear oil: |
|
|
|
| General Information |
| Clutch: |
Automatic CTV with reverse |
| Driveline / Driving wheel: |
Dual wheel drive |
| Suspension, F / R: |
F:Dual A-arm with two shock absobers
R:Independent Swingarm/Double oil damped shock |
| Brakes, F / R: |
Front and rear disk brake |
| Tires, F / R: |
20x7-8 / 22x10-10 |
| Fuel capacity: |
2.25 gal |
| Weight, G.W. / N.W.: |
280Kg/326Kg |
| Max load: |
500 lbs |
|
| Dimension Information |
| Wheelbase: |
66.1 inches |
| OA L x W x H: |
87x53.5x56.6 inches |
| Height to seat: |
13.8 inches |
| Min ground clearance: |
8.5 inches |
| Pedal to seat back distance: |
39'' to 43'' |
| Qty/Container: |
30pcs/40HQ |
|
Colors
|
RED
BLUE
BLACK
YELLOW
ORANGE
PINK
SILVER |
|
|
